SENSOR
|
1280 * 720 CMOS
|
|
LIGHT SOURCE
|
White LED
|
|
SYMBOLOGIES
|
2D:PDF417，Data Matrix，QR，Micro QR 1D:Code 128，UCC/EAN-128，AIM 128，EAN-8，EAN-13，UPC-E，UPC-A，Interleaved 2 of 5，Industrial
25，Standard 25，Code 39， Codabar，Code 93，Code 11，ITF-6，ITF-14，ISSN，ISBN，Plessey，MSI-Plessey etc.
|
|
RESOLUTION
|
≥3.9mil
|
|
DEPTH OF FIELD
|
EAN-13(13mil):35mm-180mm QR Code(15mil):5mm-75mm PDF417(6.7mil):20mm-130mm Data Matrix(10mil):15mm-75mm Mobile-Bus Code:70mm-280mm
|
|
PRINT CONTRAST RATIO
|
≥30%
|
|
READING ANGLE
|
Skew ±50°，Pitch : ±50°，Roll : 360°
|
|
FIELD OF VIEW
|
Horizontal :66°，Vertical :52°，Diagonal:78°
|
|
|
|
INTERFACE
|
USB(HID,CDC，HIDPOS)、TTL232、RS232 (Optional)
|
|
DIMENSIONS(mm)
|
53.4 x 33.4 x 19.5 ( L x W x H)
|
|
WEIGHT
|
30g
|
|
WORKING VOLTAGE
|
DC 5.5~3.3V
|
|
RATED POWER
|
1W
|
|
CURRENT 5V DC
|
Maximum :300mA Working : 200mA
|
|
ENVIRONMENTAL
|
|
|
OPERATING TEMPERATURE
|
-10°C - +50°C
|
|
STORAGE TEMPERTURE
|
-10℃~+60℃
|
|
HUMIDITY
|
5% - 95%(no-condensing)
|
|
AMBIENT LIGHT
|
0 ~100,000LUX
|
|
|
Test conditions: ambient temperature: 25℃±2℃;Ambient illumination: 200LUX incandescent lamp;Paper barcode using the test sample
code from the supplier.
|
